Macina Chacana 691

E-SYSTEM           BOSCH PT-CX6P4

Rahmen              Macina Chacana 29" Alloy6061 SLL-E 125mm; PT625 Bosch Gen.4 / M-0186

GABEL   Suntour XCR 34 Air 29" LOR 130mm 15x110 taper

DÄMPFER           RockShox Deluxe Select+ 230x57.5

MOTOR               Bosch PERFORMANCE CX Gen.4 - 25km/h / 85Nm

DISPLAY              Bosch PURION LCD Display

BATTERY             Bosch PowerTUBE 625Wh hor.

LADEGRÄT          Bosch STANDARD Charger 4A

SCHALTWERK    Shimano Deore M5100-11 SGS shadow+

SCHALTHEBEL    Shimano Deore M5100-11

KURBEL               KTM COMP ISIS 170mm Q16

VORDERES KETTENBLATT            FSA Megatooth steel 36T with Chainguard

HINTERES KETTENBLATT              Shimano Deore M5100-11 / 11-51

KETTE    KMC e11 Sport EPT e-bike

BREMSE              Tektro HD-M535 4-Piston

BREMSSCHEIBE                Tektro TR-45 2.3mm CL 203 / TR-45 2.3mm CL 180

VORDERRAD      KTM Line - Shimano MT410B CL 32H 110-15TA / Ambrosio E30 Trail 32H 622x30TC / DT Champion 2.0 black

HINTERRAD        KTM Line - Shimano MT400B CL 32H 148-12TA / Ambrosio E30 Trail 32H 622x30TC / DT Alpine II 2.34 black

VORDERREIFEN                Schwalbe Johnny Watts Perf. DD RaceGuard 60-622

HINTERREIFEN   Schwalbe Johnny Watts Perf. DD RaceGuard 60-622

HANDGRIFF        KTM Comp Lock

LENKER               KTM Comp rizer15 720mm

LENKERVORBAU              KTM Comp 7°

GABELLAGERUNG           KTM Team MTB 1.1/8"-1.5" angle limit

SATTEL KTM Line Sport

SATTELSTÜTZE KTM Comp 30.9/400

PEDALE               MTB-Pedal flat VPE-527 alloy

GEWICHT            25,6 kg

HÖCHSTZULÄSSIGES GG.        144 kg
